Nasan Industrial Tea Drying Machine

Nasan Industrial Tea Drying Machine

Product Description Nasan Industrial Tea Drying Machine Model Unit NT-18 NT-30...
  • US $10,000 - 20,000/ Set | Get Latest Price
  • Standard Export Woodencase Suitable for Ocean Carriage
  • Within 15 or 45 working days after receiveing the deposit
  • 30% as deposit in advance,70% should be paid before shipment.
  • 100 Set/Sets per Month
  • Shandong, China (Mainland)
  • LD
  • ISO 9001, CE Certificate
  • Nasan Industrial Tea Drying Machine
Product Groups

Allen

Mobile : 86-18660125156

Tel : 0531-85064681

Request a quote

Address:No.4087 SHAHEXI ROAD, TIAOQIAO DISTRICT,JINAN,CHINA

Product Description

Product Description

Nasan Industrial Tea Drying Machine



Model

Unit

NT-18

NT-30

NT-60

NT-90

NT-120

NT-200

NT-300

Microwave power

KW

18

30 60 90 120 200 300

Max Water Vaporize

Kg/h

20

34

68

100

135

230

350

Apparent Power

KVA

≤24

≤40

≤72

≤108

≤144

≤240

≤360

Voltage

V

110-440

110-440 110-440 110-440 110-440 110-440 110-440

Frequency

HZ

50/60

50/60 50/60 50/60 50/60 50/60 50/60

Power Control

KW

≤±1

≤±1 ≤±1 ≤±1 ≤±1 ≤±1 ≤±1

Temperature Control

°C

≤±1

≤±1

≤±1 ≤±1 ≤±1 ≤±1 ≤±1

Drying Temperature

°C

60-200

60-200 60-200 60-200 60-200 60-200 60-200

Microwave Leakage

Mw/ cm2

≤1

≤1 ≤1 ≤1 ≤1 ≤1

≤1

Feeding Height

mm

60

60 60 60 60 60 60

Feeding Width

M

0.5-2 0.5-2 0.5-2 0.5-2 0.5-2 0.5-2 0.5-2

Conveyor speed

M/Min

0.1-3

0.1-3 0.1-3 0.1-3 0.1-3 0.1-3 0.1-3

Working Temperature

°C

-5-45

-5-45 -5-45 -5-45 -5-45 -5-45 -5-45

Working Humidity

%

≤80

≤80 ≤80 ≤80 ≤80 ≤80 ≤80

Machine Width

mm

1400

1400

1400

1400

1400

1400

1400

Machine Height

mm

1600

1800

1800

1800

1800

1800

1800

Machine Length

mm

7300

10200

15000

20500

26000

40300

59600

Machine Weight

Kg

800

1200

2000

2800

3600

5800

8000

What's Microwave dry

Microwave refers to the electromagnetic waves frequency between 300MHz-300GHz, wavelength is between 1mm to 1m. Microwave usually shows penetration, reflection and absorption characteristics. For glass, plastic and porcelain, microwave will penetrate it without being absorbed. For water and food, it will absorb microwave and heating itself. For metal material, it will reflect the microwave. Water molecule is polar molecule, it will change its polarity and friction motion cause by the effect of high speed change of high frequency electromagnetic field. Then the microwave electromagnetic field energy can be converted into heat energy, and achieve the purpose of drying. Microwave uniform heat up the material inside and outside because of the strong penetrability, will not appear outside dry but inside wet. Body heat source state formation shortens the time of heat conduction and save a lot of drying time. Microwave sterilization temperature is from 70°C to 105°C, period is from 90 to 180 seconds. Microwave thermal effects change the bacterial protein, make it lose nutrition, reproduction and survival conditions and death. Microwave electromagnetic field can make normal growth and stability of the genetic breeding of bacteria nucleic acid [RNA] and deoxyribonucleic acid [DNA] number of hydrogen bonds slack, breakage and recombination, thereby inducing genetic mutations, chromosomal aberrations and even rupture.

Microwave Drying Advantages:

1) Microwave dryer equipment effect at once, power adjustable, transmission speed adjustable, no thermal inertia residues, compare with the conventional process equipment to save energy by 50%.

2) Microwave dryer make the material itself become body heat source state, no need heat transfer process, can achieve the drying temperature within a very short time.

3) Due to the fast drying speed, microwave drying machine maximally save the activity of the materials, nutrition ingredient and the original color.

4) Microwave dryer uniform heat up the material inside and outside because of the strong penetrability, will not appear outside dry but inside wet.

5) Microwave dryer can fast sterilization under low temperature sterilization, material store for a long time will not mildew.

6) Microwave leakage control in metal drying chamber and the waveguide, no radiation damage and harmful gas emissions, not produce waste heat and dust pollution, microwave drying is efficient and economic environmental drying mode.

Related Products

Microwave dryer have 3 differrent type.

1. Tunnel microwave dryer( continue dry model, convenient with high capacity)

2. Box microwave dryer (big microwave oven)

3. Vacuum microwave dryer( Low temperature drying in vacuum condition, just like freeze drying)

Company Information

Shanghai Nasan Group Co., Ltd. located in the China's economic center Shanghai. Nasan has more than 11 years manufacturing experience of microwave dryer. Nasan has excellent quality management team, professional research team and skilled production workers ensure consistent product quality.

At present Nasan product export to more than 30 countries and regions, such as United States, Germany, Switzerland, Japan, Singapore, Malaysia, Thailand, Burma, Vietnam, India, Russia, Kazakhstan, Ukraine, Turkey, Cyprus, Bahrain, United Arab Emirates, Saudi Arabia, Kuwait, Egypt, South Africa, Nigeria, Angola, Rwanda, Tanzania, Peru, Australia, New Zealand and so on, product was well received by these client.

Nasan will insist on company spirit of "pioneering spirit, never satisfied," business philosophy of "socially responsible", company culture of "honesty, pragmatism, innovation, development ", provide better quality products and services for every client around the world.

Our Services


1. Delivery a set wearing part along with machine for free
2. Warrant is 2 years, send spare parts by express delivery for free
3. Layout design and install design for free
4. Client be trained in our factory for free
5. Engineer go to client place install machine for charge
6. Feedback with 24 hours

FAQ

Please send an message to us if you want to get more details with price, we will feedback within 12 hours.
