Stainless steel screw mixer

specifications

1.DSH Series Double Auger shaped Mixer machinery
2.Model:DSH
3.One time mixing:30-6000min

DSH Series Double Auger shaped Mixer

Main Application

The mixer is high efficient mixing equipment and widely applied in the industry of chemical,feedstuff and power mixing.

Feature:

The rotation and revolution of the mixer is controlled by a set of motors and the cycloidal pinwheel reduction device.The mixer has the features of quick mixing and wide milling.

poerating Principal:

The material is made to conduct a compound in the cone because of the rotation and revolution of the screw.There are four main motions:

(1) The revolution of the screw along the wall makes the material conduct a circumferential motion.

(2) The rotation of the screw along the wall makes the material conduct a circumferential motion.

(3) The compound motion of the rotation and revolution of the screw make partial material be absorbed into screw cylindroid,while under the action of centrifugal force the partial material in the crew cylindroid discharge radially

(4) The raised material drops under its sole weight,four motions cause convection,shearing,diffusion in the cone,and thus material gets quickly and evenly mixed.

JianLDin City LD Manufacture Co.,LDd

Main Market:

North America
South America
Eastern Europe
Southeast Asia
Africa
LDia
Mid East
Eastern Asia
Western Europe
Central America
Northern Europe
Southern Europe
Domestic Market

Model	Total volume (m3)	Loading	Max loading weight (kg)	Loosen density (rpm)
DSH-300	0.3	0.6	95	-0.8
DSH-500	0.5	0.6	190	-0.8
DSH-1000	1	0.6	380	-0.8
DSH-2000	2	0.6	720	-0.8
DSH-3000	3	0.6	1080	-0.8
DSH-4000	4	0.6	1400	-0.8
DSH-10000	10	0.6	3600	-0.8
DSH-15000	15	0.6	5400	-0.8
Material granulariLD(mesh)	Power(kw)	Mixing time(min)	Overall size(mm)	Weight(kg)
20-250	2.2	6-10	Φ900×1905	500
20-250	2.2	6-10	Φ1160×2215	600
20-250	4	6-10	Φ1450×2820	1300
20-250	5.5	6-10	Φ0×3450	1600
20-250	7.5	6-10	Φ2050×3780	2500
20-250	11	6-10	Φ2260×4210	2800
20-250	18.5	6-10	Φ3080×5810	5600
20-250	22	6-10	Φ3576×6310	6700
