High efficient and high quality rotary kiln drying gypsum powder machine manufacturer in China

High efficient and high quality rotary kiln drying gypsum powder machine manufacturer in China

  Product Description High efficient and high quality rotary kiln drying gypsum powder machine manufacturer in China Rotary kiln is the main equipment for...
  • US $10,000 - 20,000/ Set | Get Latest Price
  • Standard Export Woodencase Suitable for Ocean Carriage
  • Within 15 or 45 working days after receiveing the deposit
  • 30% as deposit in advance,70% should be paid before shipment.
  • 100 Set/Sets per Month
  • Shandong, China (Mainland)
  • LD
  • ISO 9001, CE Certificate
  • High efficient and high quality rotary kiln drying gypsum powder machine manufacturer in China
Product Groups

Allen

Mobile : 86-18660125156

Tel : 0531-85064681

Request a quote

Address:No.4087 SHAHEXI ROAD, TIAOQIAO DISTRICT,JINAN,CHINA

Product Description

 Product Description

High efficient and high quality rotary kiln drying gypsum powder machine manufacturer in China

Rotary kiln is the main equipment for sintering cement clinker. The rotary kilns produced by our company can be divided into dry process and wet process.

We can supply Pengfei brand rotary kiln (titanium pigment kiln, sintering furnace, industrial furnace, kiln, acid pellet) made by Jiangsu Pengfei Group Co., Ltd. whose specifications are

Φ3.2×52m,Φ3.5×54m,Φ4.0×60m,Φ4.3×64m,Φ4.8×74m and Φ5.0×78m and used for 8000t/d, 5000t/d and 2500t/d new dry basis complete rotary kiln equipments. Pengfei brand rotary kiln is the main equipment for calcining cement clinker and it can be used widely for cement industry, metallurgy industry, chemical industry, etc. The rotary kiln is composed of the shell, the supporting device, the supporting device with thrust roller, the driving device, the movable kiln head, the sealing device at kiln tail, the combustion device, etc. It has the simple structure and reliable operation, at the same the production process of the rotary kiln can be controlled easily.

Through the technical renovations, the rotary kiln calcining system equipment made by Pengfei has adopted the advanced hydraulic thrust roller device, the high measuring precession plunger pump, the variable speed adjusted valve, the contact graphite block sealing device and the other national advanced technologies. In order to raise up automation degree, the industrial TV has been used at the kiln head for monitoring of kiln, the simulation phosphor screen has been used for display of process flow; the infrared scanning system has been adopted for calcining zone to directly reflect the burning conditions on the computer. With the use of these new of these new technologies, it is direct in vision, convenient in operation and reliable in use. Therefore, the thermal condition can be stabilized and the running rate of equipment can be raised. Compared to same sized equipment, its running rate has been raised 10% up, production has been increased 5-10% and heat consumption has been reduced 15% down.

Specification(m)

φ2.8or2.5×44

φ3×48

φ3.2×50

φ3.3×50

φ3.5×54

φ4×60

φ4.3×64

φ4.8×74

φ5×74

φ5.6×87

φ6.0×95

Capacity(tpd)

300

600-700

1000

1200

1500-1800

2500

3500

5000

6000

8000

10000

Slope of the kiln shell (%)

3.5

3.5

3.5

4

4

4

4

4

4

4

4

Rotary speed of kiln

Main driving (rpmin)

0.445 to 2.22

0.676 to 3.38

0.36 to 3.57

0.36 to 3.57

0.39 to 3.9

0.41 to 4.07

0.4 to 4.0

0.35 to 4

0.35 to 4

Max 4.23

Max 5

Auxiliary driving (rpmin)

4.75

9.36

6.5

5.61

7.66

8.2

7.93

8.52

7.58

8.7

9.2

weight(t)

177

213

280.6

317

341

434

562

854

885

1201

1580

Company Information

The advantage of the position

Pengfei group has the important location, and it is the largest production & export base of large size rotary equipment in China’s coastal area. The advantage of the position: Jiangsu Pengfei Group Co., Ltd locates the main transportation county in the middle of Jiangsu province-Haian county. It takes two hours from the company to the international cosmopolis Shanghai City. The international Nantong port and Shanghai port which locates in the Yangtse River Estuary make the large-sized equipment export from our company very convenient.

Scope of business

1, It has the great comprehensive ability to provide best quality service on turn-key basis with technology design, complete plant, erection and debugging, commissioning for the new type dry process rotary kiln cement production enterprise under the daily capacity of 10000T.

2, It supplies complete equipments and technical services of grinding, calcination, oil extraction, crushing, dust collecting, conveying and lifting for the metallurgy, the chemical industry, the electrical power, the mine, the coal, the oil, the environmental protection enterprises, etc.

The products covering

The total amount in the cement machinery industry is second rank among the same business and top rank in Jiangsu. The products have been sold well all over the country and exported to more than 40 countries and areas such as Germany, Russia, Japan, Korea, Brazil, Egypt, Iran, Bangladesh, Pakistan, Turkey, Myanmar, Vietnam, Columbia, South America, etc.

General introduction of the company

The company has the six subsidiary companies such as the mechanical plant, installation plant, electronic plant, casting plant, installation plant, the new type construction material plant, etc. it covers an area of 350000m2 , and has 0.82billion RMB of total assets. There are 1500 personnel and 450 engineers and technicians, the annual manufacturing capacity reaches 300000t. Pengfei has already reached the capacity to manufacture 400 sets of large ball mills, 300 sets of roller press, 260 sets of pre grinding equipments and 150 sets of large rotary kiln per year.
