On Hot Sale Dog Feed Making Machines

On Hot Sale Dog Feed Making Machines

On Hot Sale Dog Feed Making Machines Machine description Dog feed making machines description : 1.Pet food is plant or animal material...
  • US $1,000 - 30,000/ Set | Get Latest Price
  • paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
  • 20 Set/Sets per Month Dog Feed Making Machines
  • Shandong, China (Mainland)
  • Sunward
  • CE, ISO9001
Product Groups

Allen

Mobile : 86-18660125156

Tel : 0531-85064681

Request a quote

Address:No.4087 SHAHEXI ROAD, TIAOQIAO DISTRICT,JINAN,CHINA

Product Details

Condition:New Place of Origin:Shandong, China (Mainland)
Brand Name:Sunward Model Number:TSE65-P
Application:Dog, dog, cat,fish ,etc Voltage:380v / 50Hz , etc
Power(W):80 kw Weight:4000 kg
Dimension(L*W*H):15000*2500*4000MM Certification:CE, ISO9001
Warranty:1 year After-sales Service Provided:Engineers available to service machinery overseas
product type:Dog Feed Making Machines material:Stainless steel
Processing Types:screw type extrusion Heating type:Heating rings(electric)
real power:50 kw output:100-150 kg/h
product line type:Dog Feed Making Machines product called:Dog Feed Making Machines
product line:Dog Feed Making Machines

Product Description

On Hot Sale Dog Feed Making Machines

On Hot Sale Dog Feed Making Machines Machine description

Dog feed making machines description :

1.Pet food is plant or animal material intended for consumption by dogs or other canines. In extru

der, the ingredients are cooked under intense heat and pressure as it moves toward the open end

of the extruder where ingredients pass through a shaping die and knife.

2. Raw materials :

Dog feed making machines adopts corn flour, bone meal, fish meal and other grain flour

as raw materials

3. Output can be 150kg/h, 240kg/h, 500kg/h, 1ton---3ton/h

parameter TSE-65 TSE-70 TSE-85
Installed capacity 80 kw 110 kw 150 kw
Real power 50 kw 80 kw 100 kw
Output 100-150 kg/h 200-260 kg/h 400-500 kg/h

4. Flow chart :

Mixing system---Extrusion system----Drying system----Flavoring system--Packing system

5. Voltage in China :

Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to customers'

Local voltage according to different countries

6. All the machines are made by stainless steel, this line is with reasonable design and with high

automation; the screws are made by alloy steel, with building block system structure and

self-cleaning function

Main machine

Main Machines' Introduction :

Twin-screw Extruder Introduction :

On Hot Sale Dog Feed Making Machines

1.The main extruder adopts frequency speed controlling with high automation and stable performation.

2.The screws are made of the alloy steel and special craft,durable usage,high pressure,the screw life

is longer.

3.Adopting the building block structure and combining willingly according to the different demand.

4.The forced lubrication system,so that it can guarantee the equipment transmission life is longer.

5.Auto-temperature control system, make the temperature controlling more direct viewing and the par

ameter more precise.

6.Self-cleaning, screws can be cleaned by reputing wasted material.

7.According to different screw design rate to full different technology request.

8.With different structure, it is used in human food area and pet food area.

Electric Oven Introduction :

On Hot Sale Dog Feed Making Machines

1.Food grade stainless steel mesh conveyor belt,free of damage to animal or human body.

2.Drying temperature and time can be adjusted through the button on controller.

3.World famous brand of electric parts,such as LG,FUJI,and Omron etc

4.Various heating types are available, such as electric,gas,LPG,diesel and team.

5.For small granule,mesh cloth need to put on conveyor belt to avoid leakage from the mesh.

6.Different types of dryer can be made according to users' requirement based on layer,lenth,

heating type,machine material etc.

Dog food Samples

Dog Feed Samples :

On Hot Sale Dog Feed Making Machines On Hot Sale Dog Feed Making Machines

Packaging & Shipping

Shipping & Packaging :

On Hot Sale Dog Feed Making Machines Our Services

Pre-sale service :

(1)Related machines’s technical parameter will be supplied to customer.

(2)According to customer’s factory size, factory layout can be provided in advance.

(3)According to customer’s material cost, general formulation can be prepared well.

(4)Special machine can be supplied as customer’s request.

(5)Professional Advice about Market, machines, processing , materials, packing can be

supplied

(6)Suggesting professional ship agent or helping book ship as customer request.

After-sale service :

(1)Allocation chart as the buyer’s request will be supplied.

(2)Operation manual will be supplied after shipment.

(3)One year warranty, life time maintenance with cost price.

(4)Free easy broken spare parts will be sent with container .

(5)First installation can be done by engineer.

(6)Training workers in customers factory.

Our customers

Our International Partners show:

On Hot Sale Dog Feed Making Machines On Hot Sale Dog Feed Making Machines Company Information

Welcome warmly to our company :

Jinan Sunward Machinery Co.,Ltd is an industry and trade integrated enterprise. The company is

committed to R & D extrusion machinery and related ancillary equipments. It is covering mainly m

achinery and equipment for corn meal milling system,corn flakes/breakfast cereal system, baby f

ood system, corn puff snacks system,pellets system, artificial rice system,soy nuggets system; as

well as pet food/fish food system.

On Hot Sale Dog Feed Making Machines

Our machines have been exported to many countries of Asia, America, Africa, Europe etc. Machi

nes are welcome in the countries. So until now, there are not only direct customers, but also some

long term cooperation agents. Such as Indonesia agent, Iran agent, Nigeria agent and so on.

Don’t hesitate to contact us. Sunward team from pre- service to after-service will prove your choice

is worth it.
